Lenovo IdeaCentre Mini Intel Core 5 210H Processor

Key Features and Specifications

Model: Lenovo IdeaCentre Mini (91B20033HA)

Processor: Intel Core™ 5 210H, 8C (4P + 4E) / 12T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.6GHz, 12MB Intel® Smart Cache

Memory: 1x 8GB SODIMM DDR5-5600

Storage: 512GB SSD M.2 2280 PCIe 4.0×4 NVMe

Graphic: Integrated Intel Graphics

Processor: Intel Core™ 5 210H, 8C (4P + 4E) / 12T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.6GHz, 12MB Intel® Smart Cache

Graphics: Integrated Intel® Graphics

Chipset: Intel® SoC Platform

Memory: 1x 8GB SODIMM DDR5-5600

Memory Slots: Two DDR5 SODIMM slots, dual-channel capable

Max Memory: Up to 32GB DDR5-5600

Storage: 512GB SSD M.2 2280 PCIe® 4.0×4 NVMe®

Optane Memory: None

Max Storage Support: Up to two drives, 2x M.2 SSD
• M.2 SSD up to 1TB each

Card Reader: No Card Reader

Optical: None

Audio Chip:
High Definition (HD) Audio, Realtek® ALC256 codec
24-bit DAC supports 44.1K/48K/96K sample rate, 2 channel DAC supports 24-bit PCM format
16-bit ADC supports 44.1K/48K/96K sample rate, 2 stereo ADC supports 16-bit PCM format

Speakers: No speakers

Power Supply: 150W 92%

Keyboard: None

Mouse: None

Expansion Slots: Three M.2 slots (one for WLAN, two for SSD)

Case Color: Luna Grey

System Fan: 2x default

Stand: None

Pen: Pen Not Supported

Form Factor: Tiny (1L)

Dimensions (WxDxH): 191 x 195 x 42.7mm (7.52 x 7.677 x 1.68 inches)

Weight: Around 1.8 kg (3.97 lbs)

WLAN + Bluetooth: Wi-Fi® 6E, 802.11ax 2×2 + BT5.3

WWAN: WWAN Not Supported

Ethernet: 2.5GbE (RJ-45)

Front Ports:
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2)
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On
1x headphone / microphone combo jack (3.5mm)

Rear Ports:
1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 1.4
1x USB-A (Hi-Speed USB / USB 2.0)
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4b
1x Ethernet (RJ-45)
1x power connector

Security Chip: Firmware TPM 2.0 integrated in SoC

Base Warranty: 1-year, Onsite

Operating System: None
